Product Description
The Wafer Type Spring Loaded Check Valve is designed to prevent reverse flow
while providing reliable, maintenance-free operation in compact piping systems. Its flangeless
wafer design allows easy installation between ASME B16.5 flanges, reducing space and weight
requirements. Manufactured from high-quality cast iron, carbon steel, and stainless steel
materials, this valve offers excellent sealing performance and durability for demanding industrial
applications, including corrosive and hazardous media.
| Specification | Details |
|---|---|
| Valve Type | Wafer Type, Flangeless, Spring Loaded Check Valve |
| Design | Suitable for mounting between ASME B16.5 Class 150 Flanges |
| Manufacturing Standards | BS 1868, API 6D |
| Size Range | 50 mm to 350 mm |
| End Connection | Flangeless (Wafer Type) |
| Shell Test Pressure | 15 kg/cm² (Hydrostatic) |
| Seat Test Pressure | 10 kg/cm² (Hydrostatic) |
| Body Material | Cast Iron (CI), Mild Steel (MS), Carbon Steel (CS), CF8, CF8M |
| O-Ring Material | Nitrile, EPDM, Viton, Silicone, PTFE |
| Applications | Water Treatment, Oil & Gas, Chemical Processing, Petrochemical Plants, HVAC Systems, Pharmaceutical, Food Processing, Industrial Utilities, Corrosive & Hazardous Fluid Handling |
