Product Description
USMANI Jacketed Ball Valve is specially designed for handling
temperature-sensitive media by maintaining the process temperature through an external
heating or cooling jacket. Manufactured with premium-grade carbon steel and stainless
steel materials, the valve offers reliable shut-off, low pressure drop, compact
construction, and long service life. It is suitable for chemical, pharmaceutical,
food processing, oil & gas, and other industrial applications requiring controlled
temperature flow.
| Specification | Details |
|---|---|
| Product Type | Fully Jacketed Ball Valve |
| Design | Single Piece Design, Regular (Reduced) Bore, Fully Jacketed |
| Operation | Hand Lever, Gear Operated or Pneumatic Actuator |
| End Connection | Flanged Ends |
| Size Range | ½” × 1″ to 8″ × 10″ |
| Body / Insert Material | ASTM A216 Gr. WCB, ASTM A351 CF8, CF8M, CF3 & CF3M |
| Ball Material | ASTM A351 CF8, CF8M, CF3 & CF3M Stainless Steel |
| Stem Material | AISI 410, AISI 304, AISI 316, AISI 304L, AISI 316L |
| Seat & Seal Material | Virgin PTFE, Glass Filled PTFE, Carbon Filled PTFE |
| Jacket Material | Mild Steel, SS304, SS316, SS304L, SS316L |
| Key Features | Heating/Cooling Jacket, Positive Shut-Off, High Performance, Long Service Life, Low Pressure Drop, Compact Design, Maintenance-Free Operation, Quick Action |
| Valve Design Standard | BS 5351, ANSI B16.34, API 6D |
| Pressure Testing | BS 6755 Part II, API 598, API 6D |
| Face-to-Face Standard | ANSI B16.10 |
| Flange Drilling Standard | ANSI B16.5, BS 10 Table, DIN, IS 6392 |
| Applications | Chemical Processing, Pharmaceutical, Food Processing, Oil & Gas, Petrochemical, Paint, Adhesive, Polymer, Bitumen, Resin, Steam Jacketed Systems and Other Temperature-Controlled Industrial Processes |
